CONVERT 8
Unmatched Versatility
Configure your setup with up to 8 converters, tailoring your system to your specific needs.
Choose between HDMI to SDI or SDI to HDMI conversion, adapting to any workflow.
Support for 3G and 12G formats, ensuring compatibility with the latest broadcast standards.
Advanced Audio and Timecode
Full embedded audio and timecode support, maintaining signal integrity throughout your production.
Rack mount
PRISM EIGHT Rack is designed rack mount, but is signal compatible with the Prism EIGHT field boks.
Configuration
Up to 8 converters, selectable 3G|12G, HDMI-SDI, SDI-HDMI.
Rock-Solid Reliability
Optional dual power supply for ultimate redundancy, eliminating downtime during critical live events.
Low SDI-jitter, allowing for very long SDI cable runs.
Superior Image Quality
Blackmagic Micro Converter technology delivers pristine 8-bit and 10-bit video in RGB or YUV.
Support for all SD, HD, and Ultra HD formats up to 2160p60.
Support for film rates such as 1080p24, and 4Kp24.
Rugged design
The rugged aluminium design and use of professional industry standard connectors ensures seamless connectivity and optimal performance.
Why Choose Convert 8?
Extended SDI cable lengths for flexible camera placement.
Seamless integration with a wide range of equipment.
Future-proof technology that supports the latest video standards.
Technical specifications
- Chassis: Aluminium chassis
- Power input: Neutrik True1, single or dual for redundant powersupply
- Mount: 1U 19'' rack
- Weight: 3.47kg/7.65lbs
- Dimensions (LxDxH): 482 x 233 x 44mm / 19 x 9.17 x 1.73 in
Editions
- CONVERT 8, 8x selectable modules, USB-C administration port, Single powersupply
- CONVERT 8, 8x selectable modules, USB-C administration port, Redundant powersupply
- Selectable modules:
- 3G HDMI-SDI, dual SDI output
- 3G SDI-HDMI, SDI In and Loop
- 12G HDMI-SDI, dual SDI output
- 12G SDI-HDMI, SDI In and Loop
